Globe Valve

  • Bolted bonnet
  • Outside screww & yoke
  • Rising stem
  • Flanged ends
  • Solid wedge disc
Categories: , Tags:

Description

Materterial

Parts Materials
Body Cast Iron, Ductile Iron, Stainless Steel
Bonnet Cast Iron, Ductile Iron, Stainless Steel
Stem Stainless steel
Disc Cast Iron, Ductile Iron, Stainless Steel
Disc seat ring Bronze, Stainless Steel
Body seat ring Bronze, Stainless Steel
Gland Cast Iron, Ductile Iron, Stainless Steel
Gland packing Asbestos graphite
Handwheel Cast Iron, Ductile Iron, Stainless Steel
Gasket Asbestos joint sheet
Gland bolt / nut Steel, Stainless Steel
Bonnet bolt / nut Steel, Stainless Steel
Yoke bush Brass



Dimensions

mm
inch
50
2
65
21/2
80
3
100
4
150
6
200
8
L 200 220 240 280 410 495
H 300 340 355 420 565 740
D 160 195 195 240 350 350
